- Wireless Video Transmitter/Receiver Set
- Twin Image Transmission over 2.4 & 5 GHz
- Mix up to 4 Receivers/Tablets & Phones
- 1080p60 HDMI/SDI Transmission to 1200'
- iOS/Android App with Zebra & LUT Support
- 1.3" OLED Displays >50ms Latency
- L-Series Battery Support up to 12 Hours
- Automatic Channel Selection/DC Input
- Fanless Design
- Aluminum Construction
- Accsoon CineView SE Multi-Spectrum Wireless
- Video Transmission System
- CineView Quad Transmitter
- CineView Quad Receiver
- Shoe Mount
- Limited 1-Year Warranty
Monitor your production wirelessly with the Accsoon CineView SE Multi-Spectrum Wireless Video Transmission System. This powerful and advanced SDI TX/RX system is perfect for on-set and on-location monitoring of any size production. With its silent running fanless design, this system is sure to be a crucial part of your production workflow.
Accsoon Dual-Band reliability with four antennas
-Looking for a top-of-the-line wireless video transmission system? Look no further than the Accsoon CineView SE. This innovative system uses Dual-Band technology to transmit your image on both 2.4GHz and 5GHz frequencies, meaning you'll never have to worry about drop-outs or interference. With a range of up to 1200ft, you can easily film from afar without any lag or delays. And with new best-in-class latency at under 50ms, you'll never miss a beat. Whether you're a professional videographer or just looking to up your home movie game, the Accsoon CineView SE is the perfect solution.
Smaller than ever
The Accsoon CineView SE Multi-Spectrum Wireless Video Transmission System is the perfect solution for any filmmaker or videographer looking for an easy and reliable way to wirelessly transmit video. The system includes a transmitter and receiver, both of which are incredibly small and lightweight, making it easy to transport and set up. The CineView SE also features enhanced performance over the previous CineEye 2S Pro model, making it the perfect choice for anyone looking for the best possible wireless video transmission.
SDI and HDMI
The Accsoon CineView SE Multi-Spectrum Wireless Video Transmission System is the perfect solution for any director, DP, or camera operator. The transmitter has both SDI and HDMI inputs, while the receiver has SDI and HDMI outputs, both capable of frame rates up to 1080p 60fps. It even accepts SDI level A and B signals to cater for older professional cameras. This makes the CineView SE the perfect companion for every DP, director or camera operator thanks to its compatibility with a wide range of cinema, professional and mirrorless cameras.
Accsoon CineView SE Specs
|Antenna Ports||Transmitter/Receiver: 4 x RP-SMA|
|Video I/O||Transmitter: 1 x HDMI Input |
Transmitter: 1 x BNC (3G-SDI) Input
Receiver: 1 x HDMI Output
Receiver: 1 x BNC (3G-SDI) Output
|Power||Transmitter/Receiver: 1 x Barrel 2.1 mm (16.8 VDC) Input |
Transmitter/Receiver: 1 x USB-C (5 VDC) Input
|Wireless Range||1200' / 365.8 m|
|# of Channels||20|
|Frequency Range||2412 to 2472 MHz |
5180 to 5580 MHz
5660 to 5825 MHz
|Latency||< 50 ms|
|RF Power||17 dBm|
|Wi-Fi||Wi-Fi 5 (802.11ac); Dual-Band (2.4 & 5 GHz)|
|Video Format||HDMI/SDI/Wireless |
|Audio Format||2-Channel 24-Bit 48 kHz PCM Audio|
|DC Input Power||7.4 to 16.8 VDC|
|Battery Type||Transmitter/Receiver: 1 x L-Series|
|Power Consumption||Transmitter: 4.5 W (Typical) |
Receiver: 3.5 W (Typical)
|Mounting||1 x 1/4"-20 Female|
|Operating Temperature||14 to 104°F / -10 to 40°C|
|Material of Construction||Aluminum|
|Dimensions||Transmitter/Receiver: 4.1 x 2.6 x 1.3" / 10.5 x 6.6 x 3.2 cm|
|Weight||Transmitter/Receiver: 7.4 oz / 210 g, Including Antenna|
